BECA 087A

Sliding bearings / Sintered bushings

Copie de BECA 080A (Acier)

Description

The BECA 150 - 152 - 154 profiles are single acting composite rod seals composed of a filled PTFE friction ring and pre-tightened rubber O'Ring. They can be assembled in grooves according to standard ISO 7425/2. Option of connecting the seal to a back-up ring.

Advantages

Optimal sealing in static and dynamic applications
Low friction coefficient; no stick-slip effect
Excellent abrasion and extrusion resistance
Wide temperature range and excellent chemical resistance, depending on the material selected for the O'Ring

Applications

Mobile machinery
Injection presses
Machine tools
Presses
Standard cylinders

Download

Product data - Hydraulic rod seal - BECA 150 - 152 - 154 Product catalog - Hydraulic seals - Rod seals Product catalog - Hydraulic seals

Dimensions

Technical data

Dimensions

Installation drawing Logement Gorge joint de tige Housing Groove rod seal BECA 150 - 152 - 154

Technical data

Housing Groove Gland Rod Seal - BECA 150 - 152 - 154

Extrusion gaps

Radial section S	Radial extrusion gap F/2
Radial section S	10 MPa	20 MPa	40 MPa
2.45	0.30	0.20	0.15
3.65	0.40	0.25	0.15
5.35	0.50	0.30	0.20
7.55	0.70	0.40	0.25
10.25	0.80	0.60	0.35
12.00	0.90	0.70	0.40
13.65	1.00	0.80	0.50
19.00	1.20	0.90	0.60

Surface roughness

Roughness	Dynamic surface area	Static surface area	Groove flanks
Ra	0.05 - 0.2 µm	≤ 1.6 µm	≤ 3.2 µm
Rz	0.40 - 1.6 µm	≤ 6.3 µm	≤ 10.0 µm
Rmax	0.63 - 2.5 µm	≤ 10.0 µm	≤ 16.0 µm

Chamfers and radius

Radial section S	Radius R1	Radius R2	Chamfer C
2.45	0.30	0.40	3.00
3.65	0.30	0.60	3.00
5.35	0.30	1.00	3.00
7.55	0.30	1.30	5.00
10.25	0.30	1.80	6.00
12.00	0.30	1.80	8.00
13.65	0.30	2.50	10.00
19.00	0.30	3.00	12.00

353 dimensions found

087-150407A Standard request
087-250608A Standard request
087-030605A Standard request
087-030608A Standard request
087-030806A Standard request
087-030807A Standard request
087-040704A Standard request
087-040708A Standard request
087-040804A Standard request
087-040808A Standard request
087-040810A Standard request
087-040812A Standard request
087-041010A Standard request
087-050808A Standard request
087-050810A Standard request
087-050905A Standard request
087-050909A Standard request
087-050911A Standard request
087-051005A Standard request
087-051010A Standard request
087-051014A Standard request
087-060806A Standard request
087-060808A Standard request
087-060906A Standard request
087-060909A Standard request
087-061005A Standard request
087-061006A Standard request
087-061008A Standard request
087-061010A Standard request
087-061012A Standard request
087-061014A Standard request
087-061206A Standard request
087-061212A Standard request
087-061215A Standard request
087-061216A Standard request
087-061225A Standard request
087-061412A Standard request
087-071108A Standard request
087-071113A Standard request
087-071313A Standard request
087-071315A Standard request
087-071322A Standard request
087-071325A Standard request
087-071410A Standard request
087-081116A Standard request
087-008012A Standard request
087-081210A Standard request
087-081212A Standard request
087-081213A Standard request
087-081214A Standard request
087-081310A Standard request
087-081408A Standard request
087-081414A Standard request
087-081416A Standard request
087-081610A Standard request
087-081616A Standard request
087-081625A Standard request
087-091218A Standard request
087-091408A Standard request
087-091416A Standard request
087-101312A Standard request
087-101318A Standard request
087-010075A Standard request
087-101410A Standard request
087-101412A Standard request
087-101414A Standard request
087-101415A Standard request
087-101416A Standard request
087-101418A Standard request
087-101420A Standard request
087-101510A Standard request
087-101515A Standard request
087-101518A Standard request
087-101520A Standard request
087-101610A Standard request
087-101612A Standard request
087-101615A Standard request
087-101616A Standard request
087-101620A Standard request
087-101625A Standard request
087-101632A Standard request
087-102030A Standard request
087-121410A Standard request
087-121416A Standard request
087-121510A Standard request
087-121512A Standard request
087-012128A Standard request
087-121515A Standard request
087-121518A Standard request
087-121608A Standard request
087-121612A Standard request
087-121614A Standard request
087-121615A Standard request
087-121616A Standard request
087-121620A Standard request
087-121625A Standard request
087-121630A Standard request
087-121712A Standard request
087-121718A Standard request
087-121721A Standard request
